Operation

IndicatorsaboutLowDEFLevel(ForVehiclesEquippedwithCummins

X15Engines)(cont.)

LevelIndicationAudibleAlarmLCDTextMessageVehicleConditions/Operation

(Flashing)

(Solid)

1beep

ScrollsbetweenSEEVISOR

FORINFO,DEFLOWENG

DERATED40%,andWARN

ENGINE.

EngineperformanceisLIMITED.

DEFlevelis0%.

(Flashing)

(Solid)

1beep

ScrollsbetweenSEEVISOR

FORINFO,DEFLOWENG

DERATED5MPH,WARN

ENGINE,andSTOPENGINE.

Vehiclespeedislimitedto5mph

(8km/h).

179
