Navistar International LT Series

To Next Page

To Previous Page

Operation

IndicatorsaboutDEFQualityProblem(ForVehiclesEquippedwithInternational

A26Engines)(cont.)

LevelIndicationAudibleAlarmLCDTextMessageVehicleConditions/Operation

(Flashing)

(Solid)

Repetitiveshortbeeps

DEFQUALITYENGINE

DERATED5MPH.

Engineperformanceisderated.

Vehiclespeedislimitedto5mph(8

km/h).

184
