Define the media series
Introduction
You must indicate in the Océ Express WebTools the media series that you use on your
system.
Note:
Before you can edit a setting or a settings group, you must be logged on as a key operator
or power user.
How to define the media series / sizes
1.
Navigate to 'Preferences' - 'System settings' - 'Regional settings'.
2.
Click the value for 'Media series' to access the edit window and select the correct media
series.
For standard formats listed below, the shortest dimension is the supported roll width in
the media series.
If you want to select a new media series in your submission tool, only the sizes in the
defined media series are available.
#
Group / ValuesSetting
'DIN: A0, A1, A2, A3, A4, E+ (36 inch), ISO B1, ISO B2''Media series'
'DIN limited: A0, A1, A2, A3, A4, E+ (36 inch)'
'DIN carto: A0, A1, A2, A3, A4, E+ (36 inch), 500 mm, 700
mm'
'ANSI small: E, D, C, B, A, E+ (36 inch), 30 inch'
'ANSI small (extended): E, D, C, B, A, E+ (36 inch), 30 inch,
21 inch, 15 inch'
'ANSI mixed: E, D, C, B, A, E+, D+, C+, B+, A+, 30 inch'
'ANSI mixed (extended): E, D, C, B, A, E+, D+, C+, B+, A+,
30 inch, 21 inch, 15 inch'
'Japan: A0, A1, A2, A3, A4, E+ (36 inch), 880 mm, 800 mm,
660 mm, 440 mm'
3.
Click 'Ok' to confirm your entries or 'Cancel' to reject your entries.
Chapter 3 - Define your workflow with Océ Express WebTools110
Define the media series
