Oce PlotWave 900 User Manual

Media types, material and sizes on the printer
Introduction
One of the features of the Océ PlotWave 900 printer is the automatic media change
function. This function enables the printer to switch to another roll of the same media
when there is not enough media on the current roll to finish the print run. Specify media
type and the media size after you load media, as described in ‘Replace/Load a roll of media’
on page 264. The Océ PlotWave 900 supports both DIN and ANSI media formats. See
‘Preferred Océ media types and sizes’ on page 374 for an overview of all materials that can
be used on the Océ PlotWave 900 printer.
Set media type
1.
Press the “Online” key on the printer operator panel to put the printer offline. The message
“Offline” is displayed in the status window. The focus shifts to the Media option (indi-
cated by the shadow effect).
Ready to print
[18] The printer operator panel in offline mode
2.
Use the arrow keys to select the roll for which you have just loaded new media.
3.
Press the right selection key to activate the ‘Type’ option. The dotted line around the
current selection changes into a solid line and the small selection triangles next to the
specified material are no longer dimmed.
4.
Use the arrow keys to select the type you just loaded.
5.
Press the “Online” key to put the printer online again. The printer now knows which
type is used for the specified roll.
Set media material
1.
Press the “Online” key on the printer operator panel to put the printer offline. The message
“Offline” is displayed in the status window.
Chapter 2 - Get to know the Océ PlotWave 900 system 37
Media types, material and sizes on the printer
