Scanner operator panel
Introduction
The Océ PlotWave 900 is a very user-friendly system. The Océ TDS600 scanner, in
particular, is very easy to operate. Basic copy jobs can be performed by simply pressing
the green start key on the scanner operator panel. You have to change the default copy
settings with the help of the other settings on the scanner operator panel only if you want
to perform more complex copy jobs.
The operator panel is located above the original feed. The panel consists of a display in
the centre surrounded by a number of function, section and arrow keys.
To the left of the display, you can find the ‘Stop’ key and below the display you can find
the ‘Start’, ‘Numeric’ and ‘Correction’ keys as well as the ‘Counter’ window.
This section consists of two parts. The first part explains the basic use of the keys. The
second part deals with special use of the display. It describes how to use the soft keys
above and along the sides of the display to define your copy settings.
Illustration
1
1 2
3
4
5
6 7
8
9 0
C
3
5
6
4
1
2
7
8
[109] scanner operator panel
The keys
With the keys on the Océ TDS600 scanner operator panel, you can make a number of
settings for the Océ PlotWave 900.
The following keys are available.
Chapter 6 - Use the Océ TDS600 scanner to copy170
Scanner operator panel
