Specify the zoom factor
Introduction
You can use the ‘Zoom’ setting to select a zoom factor.
Selecting the zoom factor
1.
Select the ‘Image’ card in the ‘Print’ section.
2.
Select Automatic, Scale table, 1:1, or set the zoom factor on the operator panel display
•
Automatic zoom selection: the system automatically calculates the zoom ratio based
on the original size and the output media size
•
Scale table: Select a setting in the scale table. Example: A2 -> A2 or A2 -> A1.
•
1:1: Results in an image that is exactly the same size as the original.
•
Set the zoom factor on the operator panel display:
Use the arrow keys on the right of the display.
If you press one of the vertical keys, the zoom factor will increase or decrease in incre-
ments of 0.1%.
If you press one of the horizontal keys, the zoom factor will increase or decrease in
the increments predefined in the Océ Express WebTools.
Use the numeric keys at the bottom of the scanner operator panel. You can specify
the exact zoom factor in 0.1% increments.
For example, if you want to specify a zoom factor of 25.4%, you enter 254. If you
want to specify a zoom factor of 254%, you enter 2540.
[105] Select the zoom factor
Note:
You can also select the zoom factor from the ‘Custom’ section (if this setting has been
defined for this).
Chapter 5 - Use the Océ PlotWave 900 scanner to copy162
Specify the zoom factor
