Quick Steps for Configuring MCLAG Configuring Multi-chassis Link Aggregation
page 10-8 OmniSwitch AOS Release 7 Network Configuration Guide June 2013
OS10K [Chassis 2] -> show multi-chassis status
Multi-Chassis Operational Configured
---------------------+---------------------+-------------------
Chassis ID 2 2
Chassis Role Secondary N/A
Status Up N/A
Hello Interval 1s 1s
IPC VLAN 4904 4094
OS10K [Chassis 1] -> show multi-chassis consistency
Consistency Local Peer Status
-------------------------------+----------------+----------------+-------------
Chassis-ID 1 2 OK
Hello-Interval 1 1 OK
IPC-VLAN 4094 4094 OK
STP-Path-Cost-Mode Auto Auto OK
STP-Mode Per-VLAN Per-VLAN OK
OS10K [Chassis 2] -> show multi-chassis consistency
Consistency Local Peer Status
-------------------------------+----------------+----------------+-------------
Chassis-ID 2 1 OK
Hello-Interval 1 1 OK
IPC-VLAN 4094 4094 OK
STP-Path-Cost-Mode Auto Auto OK
STP-Mode Per-VLAN Per-VLAN OK
Note. Multi chassis peers in the same domain must maintain identical configuration and operational
parameters. Ensure that the mandatory parameters are the same on both peers. For more information, see
“Recommended Configuration Parameters” on page 10-33
