D. Tagged Packets with Trust VLAN Tag Enabled
Tagged packets are processed as follows when initial classification returns a UNP profile that exists but
the VLAN associated with the profile does not exist in the switch configuration:
1
In a multi-chassis link aggregation (MCLAG) configuration, after the MVRP VLAN is converted to a
UNP dynamic VLAN in the local chassis, a request is sent to the peer chassis to convert the same VLAN
to a UNP dynamic VLAN. In this case, the remote chassis will do following:
• If there is no profile with this advertised VLAN, then the request to convert is dropped.
• If there is a profile with this advertised VLAN but the VLAN doesn't exist, then the VLAN is created
as a UNP dynamic VLAN.
• If there is a profile with this advertised VLAN and the VLAN type is MVRP, this VLAN is converted
to a UNP dynamic VLAN.


D
UNP exists?


Dynamic
VLAN configuration
enabled?


VLAN in tag exists?


MVRP VLAN?


UNP exists?


Dynamic
VLAN configuration
enabled?
Create a UNP
NO NOYES YES NO
Convert MVRP VLAN
to a UNP dynamic
[End of Processing]


Dynamic
VLAN configuration
enabled?
YES
YES
NO
YES


Dynamic
VLAN configuration
enabled?
VLAN
1
NO
NO


Dynamic
profile configuration
enabled?
NO
YES
YES
Create a profile and
convert MVRP VLAN
to a UNP dynamic
VLAN
3
NO


Dynamic
profile configuration
enabled?
Create a profile and
a UNP dynamic
dynamic VLAN
2
VLAN
3
YES
YES
Tagged packets are
filtered on the tag
VLAN
[End of Processing]
NO
NO
YES
Tagged packets are
learned as forwarding
on the UNP VLAN.
The UNP port is
tagged as a member
of the UNP VLAN.
