– 468 – NWA-008845-001 Rev.5.0
32ch1008.fm
• For MCI with AP00 (PN-AP00-B with AP00 program)
DESCRIPTION DATA
Specify whether the text (Message Waiting
control text sending is available) is sent to the
VMS when the AP00 card is reset.
(1)
(2)
136
0: To send
1: Not sent
Specify the number of digits for station num-
ber in the message format to communicate
with the VMS.
(1)
(2)
137
0 : 6 digits
1 : 8 digits
Assign the attribute data, depending on the
port (Port 0-3) connected to the VMS.
(1)
(2)
See the following table.
See the following table.
NOTE 1: For the Port 1 and Port 3, data speed 9600 bps cannot be set.
NOTE 2: This data should be assigned depending on the attribute of the VMS.
NOTE 3: To send the text to the VMS successively, assign the guard timer.
D
CMD000
CMD001
AP00 INITIAL
FIRST DATA (1)
MEANING
SECOND
DATA (2)
MEANING
PORT
0
PORT
1
PORT
2
PORT
3
20 24 28 32 Data speed 2/3/4/5
NOTE 1
1200/2400/4800/9600
bps NOTE 2
21 25 29 33 Stop bit length 0 /1/2 1/1.5/2 bits NOTE 2
22 26 30 34 Data length 0 /1 7/8 bits NOTE 2
23 27 31 35 Parity 0 /1/2 None Parity/Even Par-
ity/Odd Parity NOTE 2
80 100 120 140 Equipment Type 24 MCI
81 101 121 141 Priority for data processing 0 1st Priority
85 105 125 145 Station Address (SA) 48 0
86 106 126 146 Unit Address (UA) 33 !
89 109 129 149 Timer for detecting the end of block 5 512 ms.
98 118 138 158 Guard timer between texts 0
1
2
3
4
0-128 ms.
128-256 ms.
256-384 ms.
384-512 ms.
512-640 ms.
NOTE 3
E
MESSAGE CENTER INTERFACE (MCI)
PROGRAMMING
