R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1045User Manual 1173.9411.02 ─ 43
Suffix:
<ip>
.
1 | 2
For R&S FSW85 models with two RF input connectors:
1: Input 1 (1 mm [RF Input] connector)
2: Input 2 (1.85 mm [RF2 Input] connector)
For all other models:
irrelevant
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
No data correction is performed based on the external preampli-
fier
ON | 1
Performs data corrections based on the external preamplifier
*RST: 0
Example:
INP:EGA ON
Manual operation: See "Ext. PA Correction" on page 455
INPut<ip>:GAIN:STATe <State>
This command turns the internal preamplifier on and off. It requires the optional pream-
plifier hardware.
Note that if an optional external preamplifier is activated, the internal preamplifier is
automatically disabled, and vice versa.
For R&S FSW 8 or 13 models, the preamplification is defined by INPut<ip>:GAIN[:
VALue].
For R&S FSW 26 or higher models, the input signal is amplified by 30 dB if the pream-
plifier is activated.
If option R&S FSW-B22 is installed, the preamplifier is only active below 7 GHz.
If option R&S FSW-B24 is installed, the preamplifier is active for all frequencies.
Suffix:
<ip>
.
1 | 2
For R&S FSW85 models with two RF input connectors:
1: Input 1 (1 mm [RF Input] connector)
2: Input 2 (1.85 mm [RF2 Input] connector)
For all other models:
irrelevant
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Switches the function off
ON | 1
Switches the function on
Setting Basic Measurement Parameters
