[SENSe:]MIXer<x>:HARMonic:BAND <Band>
This command selects the external mixer band. The query returns the currently
selected band.
This command is only available if the external mixer is active (see [SENSe:
]MIXer<x>[:STATe] on page 1075).
Suffix:
<x>
.
irrelevant
Parameters:
<Band> KA | Q | U | V | E | W | F | D | G | Y | J | USER
Standard waveguide band or user-defined band.
Manual operation: See "Band" on page 421
Table 14-6: Frequency ranges for pre-defined bands
Band Frequency start [GHz] Frequency stop [GHz]
KA (A) *) 26.5 40.0
Q 33.0 50.0
U 40.0 60.0
V 50.0 75.0
E 60.0 90.0
W 75.0 110.0
F 90.0 140.0
D 110.0 170.0
G 140.0 220.0
J 220.0 325.0
Y 325.0 500.0
USER 32.18
(default)
68.22
(default)
*) The band formerly referred to as "A" is now named "KA".
[SENSe:]MIXer<x>:HARMonic:HIGH:STATe <State>
This command specifies whether a second (high) harmonic is to be used to cover the
band's frequency range.
Suffix:
<x>
.
irrelevant
Parameters:
<State> ON | OFF | 1 | 0
*RST: 0
Example:
MIX:HARM:HIGH:STAT ON
