R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1075User Manual 1173.9411.02 ─ 43
● Basic Settings..................................................................................................... 1075
● Mixer Settings..................................................................................................... 1077
● Conversion Loss Table Settings..........................................................................1082
● Programming Example: Working with an External Mixer....................................1087
Basic Settings
The basic settings concern general usage of an external mixer.
[SENSe:]MIXer<x>[:STATe]...........................................................................................1075
[SENSe:]MIXer<x>:BIAS:HIGH......................................................................................1075
[SENSe:]MIXer<x>:BIAS[:LOW].....................................................................................1075
[SENSe:]MIXer<x>:LOPower........................................................................................ 1076
[SENSe:]MIXer<x>:SIGNal............................................................................................1076
[SENSe:]MIXer<x>:THReshold......................................................................................1077
[SENSe:]MIXer<x>[:STATe] <State>
Activates or deactivates the use of a connected external mixer as input for the mea-
surement. This command is only available if the optional External Mixer is installed and
an external mixer is connected.
Suffix:
<x>
.
irrelevant
Parameters:
<State> ON | OFF | 1 | 0
*RST: 0
Example:
MIX ON
Manual operation: See "External Mixer (State)" on page 420
[SENSe:]MIXer<x>:BIAS:HIGH <BiasSetting>
This command defines the bias current for the high (second) range.
This command is only available if the external mixer is active (see [SENSe:
]MIXer<x>[:STATe] on page 1075).
Suffix:
<x>
.
irrelevant
Parameters:
<BiasSetting> *RST: 0.0 A
Default unit: A
Manual operation: See "Bias Value" on page 425
[SENSe:]MIXer<x>:BIAS[:LOW] <BiasSetting>
This command defines the bias current for the low (first) range.
This command is only available if the external mixer is active (see [SENSe:
]MIXer<x>[:STATe] on page 1075).
Setting Basic Measurement Parameters
