Remote Commands
R&S
®
FSW
1092User Manual 1173.9411.02 ─ 43
RSINgle
Run single: starts one data acquisition.
NOACtion
Nothing is started on pressing the micro button.
Manual operation: See "Microbutton Action" on page 373
[SENSe:]PROBe<pb>:SETup:NAME?
Queries the name of the probe.
Suffix:
<pb>
.
1..n
Selects the connector:
1 = Baseband Input I
2 = Baseband Input Q
3 = RF
Return values:
<Name> String containing the name of the probe.
Example: //Query name of the probe
PROB3:SET:NAME?
Usage: Query only
Manual operation: See "Name" on page 371
[SENSe:]PROBe<pb>:SETup:NMOFfset <NMOffset>
Sets the N-mode offset. The setting is only available if a modular probe in N-mode is
connected to the R&S FSW. The maximum voltage difference between the positive
and negative input terminals is 16 V.
If the probe is disconnected, the N-mode offset of the probe is reset to 0.0 V.
Note that if the offset for DM-mode or CM-mode is changed, the offsets for the P-mode
and N-mode are adapted accordingly, and vice versa.
For details see "MultiMode Function and Offset Compensation for Modular RF Probes"
on page 362.
Suffix:
<pb>
.
1..n
Selects the connector:
1 = Baseband Input I
2 = Baseband Input Q
3 = RF
Parameters:
<NMOffset> The voltage offset between the negative input terminal and
ground.
Default unit: V
