Remote Commands
R&S
®
FSW
1182User Manual 1173.9411.02 ─ 43
Parameters:
<State> ON | OFF | 0 | 1
*RST: 1
Example:
CALC:MARK:FUNC:FPE:ANN:LAB:STAT OFF
Removes the peak labels from the diagram
Manual operation: See "Display Marker Numbers" on page 551
CALCulate<n>:MARKer<m>:FUNCtion:FPEaks:COUNt?
This command queries the number of peaks that have been found during a peak
search.
The actual number of peaks that have been found may differ from the number of peaks
you have set to be found because of the peak excursion.
Suffix:
<n>
.
irrelevant
<m> irrelevant
Return values:
<NumberOfPeaks>
Example:
CALC:MARK:FUNC:FPE:COUN?
Queries the number of peaks.
Usage: Query only
CALCulate<n>:MARKer<m>:FUNCtion:FPEaks[:IMMediate] <Peaks>
This command initiates a peak search.
Suffix:
<n>
.
Window
<m> Marker
Parameters:
<Peaks> This parameter defines the number of peaks to find during the
search.
Note that the actual number of peaks found during the search
also depends on the peak excursion you have set with
CALCulate<n>:MARKer<m>:PEXCursion.
Range: 1 to 200
Example:
CALC:MARK:PEXC 5
Defines a peak excursion of 5 dB, i.e. peaks must be at least 5
dB apart to be detected as a peak.
CALC:MARK:FUNC:FPE 10
Initiates a search for 10 peaks on the current trace.
Analyzing Measurements (Basics)
