New Table................................................................................................................... 426
Edit Table.................................................................................................................... 426
Delete Table................................................................................................................ 426
Import Table................................................................................................................ 426
New Table
Opens the "Edit conversion loss table" dialog box to configure a new conversion loss
table.
For details on table configuration, see "Creating and Editing Conversion Loss Tables"
on page 426.
Remote command:
[SENSe:]CORRection:CVL:SELect on page 1086
Edit Table
Opens the "Edit conversion loss table" dialog box to edit the selected conversion loss
table.
For details on table configuration, see "Creating and Editing Conversion Loss Tables"
on page 426.
Remote command:
[SENSe:]CORRection:CVL:SELect on page 1086
Delete Table
Deletes the currently selected conversion loss table after you confirm the action.
Remote command:
[SENSe:]CORRection:CVL:CLEar on page 1084
Import Table
Imports a stored conversion loss table from any directory and copies it to the instru-
ment's C:\R_S\INSTR\USER\cvl\ directory. It can then be assigned for use for a
specific frequency range (see "Conversion Loss" on page 422).
Remote command:
MMEM:COPY '<conversionlosstable>',C:\R_S\INSTR\USER\cvl\
See MMEMory:COPY on page 1231
Creating and Editing Conversion Loss Tables
Access: [INPUT/OUTPUT] > "External Mixer Config" > "Conversion Loss Table" >
"New Table" / "Edit Table"
Conversion loss tables can be newly defined and edited.
Note that only common conversion loss tables (in .acl files) can be edited. Special
conversion loss tables (in .b2g or .b5g files) can only be imported and deleted.
For details see "External Mixers and Large Bandwidth Extension Options"
on page 413.
A preview pane displays the current configuration of the conversion loss function as
described by the position/value entries.
Data Input and Output
