Data Management
R&S
®
FSW
630User Manual 1173.9411.02 ─ 43
Access: "Save"/ "Open" icon in the toolbar > "Save" / "Recall"
Both dialog boxes are very similar and closely related.
Selecting Storage Location - Drive/ Path/ Files...........................................................630
File Name....................................................................................................................631
Comment.....................................................................................................................631
File Explorer................................................................................................................631
File Type......................................................................................................................631
Items:.......................................................................................................................... 631
Save File..................................................................................................................... 631
Recall in New Channel / Recall in Current Channel....................................................632
Selecting Storage Location - Drive/ Path/ Files
Select the storage location of the file on the instrument or an external drive.
The default storage location for the SEM settings files is:
C:\Program Files (x86)\Rohde-Schwarz\FSW\<version>\sem_std.
Note: Saving instrument settings in secure user mode.
In secure user mode, settings that are stored on the instrument are stored to volatile
memory, which is restricted to 256 MB. Thus, a "memory limit reached" error can occur
although the hard disk indicates that storage space is still available.
To store data permanently, select an external storage location such as a USB memory
device.
Storing and Recalling Instrument Settings and Measurement Data
