Manual operation: See "Channel Names" on page 177
[SENSe:]POWer:ACHannel:NAME:ALTernate<ch> <Name>
This command defines a name for an alternate channel.
For MSR ACLR measurements, this command defines the name for the lower alternate
channel in asymmetric channel definitions. To define the name for the upper alternate
channels use the [SENSe:]POWer:ACHannel:NAME:UALTernate<ch> command.
Suffix:
<ch>
.
1..n
Alternate channel number
Parameters:
<Name> String containing the name of the channel
*RST: ALT<1...11>
Manual operation: See "Channel Names" on page 177
[SENSe:]POWer:ACHannel:NAME:CHANnel<ch> <Name>
This command defines a name for a transmission channel.
Suffix:
<ch>
.
1..n
Tx channel number
Parameters:
<Name> String containing the name of the channel
*RST: TX<1...12>
Manual operation: See "Channel Names" on page 177
[SENSe:]POWer:ACHannel:SPACing[:ACHannel] <Spacing>
This command defines the distance from transmission channel to adjacent channel.
For MSR signals, this command defines the distance from the CF of the first Tx chan-
nel in the first sub block to the lower adjacent channel. To configure the spacing for the
upper adjacent channel in asymmetrical configurations, use the [SENSe:]POWer:
ACHannel:SPACing:UACHannel command.
A change of the adjacent channel spacing causes a change in the spacing of all alter-
nate channels below the adjacent channel (not for MSR signals).
Parameters:
<Spacing> Range: 100 Hz to 2000 MHz
*RST: 14 kHz
Default unit: Hz
Manual operation: See "Channel Spacings" on page 175
See "Adjacent Channel Spacings" on page 187
