R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
879User Manual 1173.9411.02 ─ 43
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:UPPer:ACLR[:RELative]
<SBGaps>, <Limit>
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:UPPer:ACLR[:RELative]?
<SBGaps>
This command defines the relative limit for the ACLR power in the specified upper gap
channel. The reference value for the relative limit is the measured channel power.
If you define both an absolute limit and a relative limit, the R&S FSW uses the lower
value for the limit check.
Suffix:
<n>
.
irrelevant
<li> irrelevant
<gap> 1 | 2
Gap channel number
Parameters:
<Limit> Defines the relative limit for the ACLR power in the specified gap
channel in dB.
Default unit: DB
Parameters for setting and query:
<SBGaps> AB | BC | CD | DE | EF | FG | GH
Name of the gap, defined by the letters of the surrounding sub
blocks (e.g. "AB" for the gap between sub blocks A and B).
Example:
CALC:LIM:ACP:GAP1:MAN:UPP:ACLR:REL AB,3dB
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:UPPer:ACLR[:RELative]:
STATe <SBGaps>, <State>
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:UPPer:ACLR[:RELative]:
STATe? <SBGaps>
This command turns the relative limit check for the specified upper gap (CACLR) chan-
nel on and off.
You have to activate the general ACLR limit check before using this command with
CALCulate<n>:LIMit<li>:ACPower[:STATe].
Suffix:
<n>
.
irrelevant
<li> irrelevant
<gap> 1 | 2
Gap (CACLR) channel number
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Switches the function off
