Getting Started
R&S
®
FSW
88User Manual 1173.9411.02 ─ 43
Sa SAMPLE detector
Av AVERAGE detector
Rm RMS detector
QP QUASIPEAK detector
(4) Trace Mode
Sweep mode:
Clrw CLEAR/WRITE
Max MAX HOLD
Min MIN HOLD
Avg AVERAGE (Lin/Log/Pwr)
View VIEW
(5) Smoothing factor Smth Smoothing factor, if enabled.
(See "Smoothing" on page 585)
Norm/NCor
Correction data is not used.
5.4.1.3 Marker Information
Marker information is provided either in the diagram grid or in a separate marker table,
depending on the configuration.
Marker information in diagram grid
Within the diagram grid, the x-axis and y-axis positions of the last two markers or delta
markers that were set are displayed, if available, as well as their index. The value in
the square brackets after the index indicates the trace to which the marker is assigned.
(Example: M2[1] defines marker 2 on trace 1.) For more than two markers, a separate
marker table is displayed beneath the diagram by default.
Marker information in marker table
In addition to the marker information displayed within the diagram grid, a separate
marker table may be displayed beneath the diagram. This table provides the following
information for all active markers:
Type Marker type: N (normal), D (delta), T (temporary, internal), PWR (power sensor)
Ref Reference (for delta markers)
Trc Trace to which the marker is assigned
X-value X-value of the marker
Y-value Y-value of the marker
Func Activated marker or measurement function
Func .Result Result of the active marker or measurement function
Operating the Instrument
