R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
925User Manual 1173.9411.02 ─ 43
[SENSe:]LIST:RANGe<ri>[:FREQuency]:STOP <Frequency>
This command defines the stop frequency of a spurious emission measurement range.
Make sure to set an appropriate span. If you set a span that is
●
smaller than the span the sweep list covers, the R&S FSW will not measure the
ranges that are outside the span - results may be invalid.
●
greater than the span the sweep list covers, the R&S FSW will adjust the start fre-
quency of the first range and the stop frequency of the last range to the span
For more information seeChapter 7.7, "Spurious Emissions Measurement",
on page 280 .
Suffix:
<ri>
.
1..n
Selects the measurement range.
Parameters:
<Frequency> Numeric value.
*RST: -2.52 MHz (range 1), 2.52 MHz (range 2), 250.0
MHz (range 3)
Default unit: Hz
Example:
LIST:RANG2:STOP 5MHZ
Manual operation: See "Range Start / Range Stop" on page 252
See "Range Start / Range Stop" on page 285
[SENSe:]ESPectrum<sb>:RANGe<ri>:INPut:ATTenuation <Attenuation>
This command defines the input attenuation for a SEM range.
In case of high speed measurements, the input attenuation has to be identical for all
ranges.
Suffix:
<sb>
.
1 to 8
Sub block in a Multi-SEM measurement
<ri> 1..n
Selects the measurement range.
Parameters:
<Attenuation> Numeric value.
Refer to the data sheet for the attenuation range.
*RST: 10 dB
Default unit: dB
Manual operation: See "RF Attenuation" on page 253
[SENSe:]ESPectrum<sb>:RANGe<ri>:INPut:ATTenuation:AUTO <State>
This command turns automatic selection of the input attenuation for a SEM range on
and off.
Configuring and Performing Measurements
