R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
924User Manual 1173.9411.02 ─ 43
<ri> 1...30
Selects the measurement range.
Parameters:
<FilterType> NORMal
Gaussian filters
CFILter
channel filters
RRC
RRC filters
CISPr | PULSe
CISPR (6 dB) - requires EMI (R&S FSW-K54) option
Return value for query is always PULS.
MIL
MIL Std (6 dB) - requires EMI (R&S FSW-K54) option
P5
5 Pole filters
*RST:
NORM
Refer to the datasheet for available filter bandwidths.
Manual operation:
See "Filter Type" on page 252
[SENSe:]LIST:RANGe<ri>[:FREQuency]:STARt <Frequency>
This command defines the start frequency of a spurious emission measurement range.
Make sure to set an appropriate span. If you set a span that is
●
smaller than the span the sweep list covers, the R&S FSW will not measure the
ranges that are outside the span - results may be invalid.
●
greater than the span the sweep list covers, the R&S FSW will adjust the start fre-
quency of the first range and the stop frequency of the last range to the span
For more information seeChapter 7.7, "Spurious Emissions Measurement",
on page 280 .
Suffix:
<ri>
.
1..n
Selects the measurement range.
Parameters:
<Frequency> Numeric value.
*RST: -12.75 MHz (range 1), -2.515 MHz (range 2), 2.515
MHz (range 3)
Default unit: Hz
Example:
LIST:RANG2:STAR 2MHZ
Manual operation: See "Range Start / Range Stop" on page 252
See "Range Start / Range Stop" on page 285
Configuring and Performing Measurements
