Remote Commands
R&S
®
FSW
944User Manual 1173.9411.02 ─ 43
Manual operation: See "Bands" on page 262
[SENSe:]ESPectrum<sb>:MSR:BCATegory <Category>
This command defines the band category for MSR measurements, i.e. the combination
of available carriers to measure.
Suffix:
<sb>
.
1 to 8
Sub block in a Multi-SEM measurement
Parameters:
<Category> 1 | 2 | 3
1
2 carriers: LTE FDD and W-CDMA
2
3 carriers: LTE FDD, W-CDMA and GSM/EDGE
3
2 carriers: LTE TDD and TD-SCDMA
*RST: 1
Example:
//Select the band category 1
ESP2:MSR:BCAT 1
//Set the base station class to medium range
ESP2:MSR:CLAS MED
//Set the maximum output power to 10 dBm.
ESP2:MSR:MPOW 10
//Set the frequency range of the base station to > 3 GHz
ESP2:MSR:BAND:HIGH
//Set the base station RF bandwidth to 20 MHz
ESP2:MSR:RFBW 20MHZ
//Calculate limits for MSR SEM
ESP2:MSR:APPL
Manual operation:
See "Band Category" on page 261
[SENSe:]ESPectrum<sb>:MSR:CLASs <Class>
Defines the class of the base station according to its sending range.
Suffix:
<sb>
.
1 to 8
Sub block in a Multi-SEM measurement
Parameters:
<Class> WIDE | MEDium | LOCal
WIDE
Wide Area
MEDium
Medium Range
