SATO CL6NX Programming Reference

110
Symbol Parameter name Setting
value
Character set
H -
I -
J CP1257 Windows Baltic
K CP869 IBM Greek
L -
M
Japanese X0201
*1
@ Unicode UTF-8
*1: Specifying X0201 prints ISO 8859-1 Latin 1 character set.
c [Font style]
0 Standard
1 Bold
2 Italic
3 Bold + Italic
d [Width]
Valid Range: 004 to 999 (dots)
Valid Range: P02 to P99 (points)
e [Height]
Valid Range: 004 to 999 (dots)
Valid Range: P02 to P99 (points)
n [Print data] = Data
[Coding Example1]
Font type: SATO CG Sleek, Width: 10 pts, Height: 10 pts
<A>
<V>100<H>100<P>2
<RD>A00,P10,P10,SATO
<Q>2
<Z>
[Supplementary Explanation]
• The font size is set by [dot number] or [point number].
• The dot size does vary with printer type. (Refer to the table below)
Head density Size of 1 dot (mm)
203 dpi (8 dots/mm) 0.125
305 dpi (12 dots/mm) 0.083
609 dpi (24 dots/mm) 0.042
• 1 point is 0.35 mm.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
