SATO CL6NX Programming Reference

191
[Supplementary Explanation]
• The inter-character pitch of the barcode is valid at CODABAR (NW-7), CODE39, Industrial 2of5
and Matrix 2of5. The barcode inter-character pitch is set by specifying the character pitch <P>
immediately before.
If not set, the inter-character pitch will be of the same size as a narrow space width.
Inter-character gapCommand Ratio Narrow
space width
<P>
Narrow bar
width: 1
Narrow bar
width: 2
Nil 2 4
<P>0 2 4
<P>1 1 2
<P>2 2 4
<P>3 3 6
<BD> 2:5 2
<P>4 4 8
• For print data of each barcode type, refer to the code tables of barcode.
• The barcode translation of following codes will be restricted to conditions below: JAN/EAN8,
JAN/EAN13, UPC-A
For 203 dpi (8 dots/mm) : Narrow bar width must be [02], [03]
For 305 dpi (12 dots/mm) : Narrow bar width must be [03], [04]
For 609 dpi (24 dots/mm) : Narrow bar width must be [06], [07] , [08]
HRI will not be printed if the value other than the listed above is specified.
[Notes]
• If the value other than valid range is set, command error will occur and barcode will not be
printed.
• Barcode will be printed even if the data exceed the printing area.
• Increasing narrow bar width may exceed the print area.
• Scanner may not read the barcode with valid character pitch when Character Pitch <P> is
increased. Also, increasing the narrow bar width may cause the same type of problem. For
more information, refer to the documentation of your scanner.
• For specifying the narrow bar width, consider the reading compatibility of scanner and head
density beforehand.
• Adjust Print Speed <CS> or Print Darkness <#F> if there is a problem in barcode reading.
• Matrix 2of5 will be expressed as Coop2of5/NEC2of5.
• If Start/Stop character is not included in print data at the time of CODABAR (NW-7) or CODE39
specified, barcode will be printed; however, scanner cannot read it.
• If sending the print data including check digit at the time of JAN/EAN-13 or JAN/EAN-8
specified, set the correct calculated value. Barcode will be printed even when the data includes
improper check digit; however, scanner cannot read it.
Parent topic Barcode Command

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
