22
Command Command name The range of Eurocode Code Page
<U> U font (Basic size 5×9 dots)
<S> S font (Basic size 8×15 dots)
<M> M font (Basic size 13×20 dots)
<WB> WB font (Basic size 18×30 dots)
<WL> WL font (Basic size 28×52 dots)
DOS 866
<$=> Outline Font Print DOS 858
<RD> CG font Eurocode shall be 00H-FFH considering
the use of GID (Glyph Index).
<RG> Multiple language Eurocode shall be 20H-FFH because
the range of character code is more than
20H.
Note: A space will be printed in case if less
than 20H is specified.
<RH> Scalable font Eurocode shall be 00H-FFH considering
the use of GID (Glyph Index).
DOS 857
DOS 858
Parent topic Font list
Limitation on non-standard codes
Non-standard codes are available only in its default setting (Refer to the following chart). If control
code is set to the same code as high-order bytes of Kanji by changing the code intentionally, it is not
possible to use half-size characters which correspond to control code.
Initial valueFunctionality Description
Standard Non-standard
STX 02H 7BH
ETX 03H 7DH
ESC 1BH 5EH
ENQ 05H 40H
Protocol code
CAN 18H 21H
Parent topic Font list
