SATO CL6NX Programming Reference

272
* Symbol size of DataMatrix (ECC200) is following 30 types.
Symbol size and number of data of DataMatrix(ECC200)
Maximum data digitsSymbol size
Number of cell
in one line(c)
Number of
cell line(d)
Number of
block
Numeric Alphanumeric Briary
Square
10 10 1 6 3 1
12 12 1 10 6 3
14 14 1 16 10 6
16 16 1 24 16 10
18 18 1 36 25 16
20 20 1 44 31 20
22 22 1 60 43 28
24 24 1 72 52 34
26 26 1 88 64 42
32 32 4 124 91 60
36 36 4 172 127 84
40 40 4 228 169 112
44 44 4 288 214 142
48 48 4 348 259 172
52 52 4 408 304 202
64 64 16 560 418 278
72 72 16 736 550 366
80 80 16 912 682 454
88 88 16 1152 862 574
96 96 16 1392 1042 694
104 104 16 1632 1222 814
120 120 36 2100 1573 1048
132 132 36 2608 1954 1302
144 144 36 3116 2335 1556
18 8 1 10 6 3
32 8 2 20 13 8
26 12 1 32 22 14
36 12 2 44 31 20
36 16 2 64 46 30
48 16 2 98 72 47
Rectangle
* Mixture of Numeric, Alphanumeric and Control code varies according to number of characters.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
