[Supplementary Explanation]
• If Parameter other than above is specified or print data do not match, printing is not performed.
• When specifying print format, secure more than 2 mm blank space in four sides of the
DataMatrix for read margin for the scanner.
• When print data is 7EH, specify [7EH, 7EH]. Number of data will be "0002".
• When [7EH] is specified solely, the command error occurs and the code will not be printed.
• When print data is 1BH, specify [1BH, 1BH]. Number of data will be "0002".
• When print data is FNC1, specify [1BH, 31H]. Number of data will be "0002".
• When [1BH] is specified solely, printing and the content of printing will not be guaranteed.
• When Auto setup (000) is applied for [Number of cell in one row] and [Number of cell lines],
square DataMatrix is printed.
• When the same value other than 000 is specified (manual setting) in the "number of cell in one
row" and "number of cell lines", square DataMatrix will be printed.
• When different value other than 000 is specified (manual setting) in the "number of cell in one
row" and "number of cell lines", rectangle DataMatrix will be printed.
• The number of data can be specified in the data part depends on the data format. Available data
number is as follows.
(Number of cell is auto setting or the maximum cell number is specified):
Data format Number of data
Numeric 3116
Alphanumeric 2335
Data format
Binary (00H to FFH) 1556
• The symbol may not be read by a scanner when the cell size is smaller. In the above case,
specify enough cell size for the scanner.
• The symbol size available in the GS1 DataMatrix is limited to the 30 types in the below table.
Also, the maximum number of data is limited depending on the symbol size. Refer to the "The
maximum digit of the number of data" table.
• Make sure to specify 1BH and 31H at the beginning of the data.
