SATO CL6NX Programming Reference

277
GS1 DataMatrix Code table
S I S O
B8 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
B7 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1
B6 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1
B5 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1
B4 B3 B2 B1 0 1 2 3 4 5 6 7 8 9 A B C D E F
0 0 0 0 0 SP 0 @ P ｀ p
0 0 0 1 1 ！ 1 A Q a q
0 0 1 0 2 ” 2 B R b r
0 0 1 1 3 # 3 C S c s
0 1 0 0 4 $ 4 D T d t
0 1 0 1 5 % 5 E U e u
0 1 1 0 6 & 6 F V f v
0 1 1 1 7 ’ 7 G W g w
1 0 0 0 8 ( 8 H X h x
1 0 0 1 9 ) 9 I Y i y
1 0 1 0 A * : J Z j z
1 0 1 1 B + ； K ［ k ｛
1 1 0 0 C ， < L ￥ l ｜
1 1 0 1 D - = M ］ m ｝
1 1 1 0 E ． > N ＾ n ~
1 1 1 1 F / ？ O ＿ o DEL
Data n Data n+1
FNC1 1BH 31H
GS1 DataMatrix can specify from 00H to FFH.
When print data is 7EH, specify [7EH, 7EH].

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
