SATO CL6NX Programming Reference

330
[Print darkness level range]
Model Head
density
Parameter valid range When setting outside of valid range
203 dpi 1, 2, 3, 4, 5
305 dpi 1, 2, 3, 4, 5
CL4NX
609 dpi 1, 2, 3, 4, 5
Command error will occur when other values than
parameter valid range in the left is specified.
203 dpi 1, 2, 3CL6NX
305 dpi 1, 2, 3
Command error will occur.
However it will work as 2 for 305 dpi when 4 or 5 is
specified.
[Print darkness range]
Parameter valid range When setting outside of valid range
A From B to F are reserved. The same darkness as A.
Print darkness other than from A to F will be replaced with A. (It will not be a
command error.)
Parent topic System Command

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
