45
[Supplementary Explanation]
• When the print start position exceeds the printing area, the printing is not performed. (This will
not be a command error.)
• Set line width according to the table below so the horizontal line width is more than 0.166 mm.
Head density Line width
203 dpi (8 dots/mm) 2 dots or more
305 dpi (12 dots/mm) 2 dots or more
609 dpi (24 dots/mm) 4 dots or more
• If setting the vertical line width wider, it will be widened to the right side against media feed
direction. If setting the horizontal line width wider, it will be widened to the lower side against
media feed direction.
• If setting the grid line wider, it will be widened inward.
[Valid Range]
Model Head density Valid range:
Horizontal (dots)
Valid range:
Vertical (dots)
203 dpi 1 to 832 1 to 20000
305 dpi 1 to 1248 1 to 18000
CL4NX
609 dpi 1 to 2496 1 to 9600
203 dpi
1 to 1216
*1
1 to 1340
*2
1 to 20000CL6NX
305 dpi
1 to 1984
*1
1 to 2010
*2
1 to 18000
*1 Valid range when "Head Base Position" is set to "Standard".
*2 Valid range when "Head Base Position" is set to "Left-justify".
