499
Detailed parameters of NFC(NDEF) support (omissible)
* For smart poster, make sure to specify the URI record. As
other records are treated as options, specify if necessary.
ptl: Protocol For ndf:1 or ndf:3 (spl:1), specify the protocol
(scheme) corresponding number to 1~3 digit decimal.
The valid range is 1 ~ 255 (refer to the table of
"Setting value of protocol (ptl:)" in [ESC+RK] RFID
write (ISO/IEC14443 TypeA)).
* Considering the extensibility of the function, only the valid
range is checked instead of its content.
ecd: Character code For ndf:2 or ndf:3 (spl:2), specify the character code.
Valid range 0 ~ 1
0: UTF-8
1: UTF-16
lgc: Language code For ndf:2 or ndf:3 (spl:2), specify the name that
complies with RFC5646 to 2 ~ 63 digit.
Usable characters are 0 ~ 9, A ~ Z, a ~ z and -
(hyphen).
E.g.: French(fr), Japanese (ja), English (en),
American English (en-US)
idt: Icon data type For ndf:3 (spl:4), specify the icon data type to MIME
type that complies with RFC2046. 1 ~ 64 digits.
E.g.: PNG image->[image/png]
ndd: Write user data Specify user data. Command error will occur if this is
not specified. The size information for the data area is
required before the data. For example, if the data size
was 64, it should be specified as ndd:64,abcde....
ndf: spl: Setting value
1 -
3 1
Specify the resource with
UTF-8 character code.
2 -
3 2
Specify any string. Specify
with consideration of
character code and language
code.
3 3 Specify the following value:
Valid range: 0 ~ 2
0: Do the action
(Send SMS to start browser)
1: Save for later (Save
process)
2: Open for editing (SMS,
URI edit)
3 4 Specify the icon data (binary
data) to hexadecimal which
digit is 2's multiples.
ver: Version For ndf:4 ~ 6, specify the handover version number to
decimal. Specify major and minor numbers delimited
by a period character. For example, specify as
ver:2.1 if the major number is 2 and minor number is
1.
