SATO CL6NX Programming Reference

538
[EXT] section
Name of Setting
item
Setting value Default Value R/W
initial
Contents of Setting item
IE
EXTSIG
"0": Disable
"1": Enable
0
R/W
○
Print start signal
EXTMODE
"0": TYPE1
"1": TYPE2
"2": TYPE3
"3": TYPE4
3
R/W
○
External signal switch
EXTRETRY
"0": Disable
"1": Enable
0
R/W
○
Signal for reprint
EXTPRTSTAT
"2": 5 pins
"4": 7 pins
2
R/W
○
Start
print signal
EXTREISUU
"2": 5 pins
"4": 7 pins
4
R/W
○
Reprint signal
EXTPAPEREND
"8": 1 pin
"2": 3 pins
"4": 4 pins
"16": 6 pins
"64": 9 pins
"32": 10 pins
"0": Do not specify
8
R/W
○
Paper end signal
EXTRBNEND
"8": 1 pin
"2": 3 pins
"4": 4 pins
"16": 6 pins
"64": 9 pins
"32": 10 pins
"0": Do not specify
2
R/W
○
Ribbon end signal
EXTMCNERR
"8": 1 pin
"2": 3 pins
"4": 4 pins
"16": 6 pins
"64": 9 pins
"32": 10 pins
"0": Do not specify
4
R/W
○
Machine error signal
EXTPRNCOMP
"8": 1 pin
"2": 3 pins
"4": 4 pins
"16": 6 pins
"64": 9 pins
"32": 10 pins
"0": Do not specify
16
R/W
○
Print complete signal
EXTOFFLINE
"8": 1 pin
"2": 3 pins
"4": 4 pins
"16": 6 pins
"64": 9 pins
"32": 10 pins
"0": Do not specify
64
R/W
○
Offline signal
EXTRBNNEAR
"8": 1
pin
"2": 3 pins
"4": 4 pins
"16": 6 pins
"64": 9 pins
"32": 10 pins
"0": Do not specify
32
R/W
○
Ribbon near end signal
EXTRDISPCOMP
"8": 1 pin
"2": 3 pins
"4": 4 pins
"16": 6 pins
"64": 9 pins
"32": 10 pins
"0": Do not specify
0
R/W ○
Dispenser
completion signal
EXTLBLNEAR
"8": 1 pin
"2": 3 pins
"4": 4 pins
"16": 6 pins
"64": 9 pins
"32": 10 pins
"0": Do not specify
0
R/W ○
Label
near end signal
EXT_9PIN
"0"
:
MODE1
(With or not remaining items
to print)
"1": MODE2
(Online / offline
status)
0
R/W ○
Output mode of 9
-
pin external signal

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
