SATO CL6NX Programming Reference

542
[SDPL] section
Name of Setting item
Setting
value
Default
Value
R/W
initial
Contents of Setting item
SD
CONTROL_CODE
"0": Standard code
"1": Alternate code 1
"2": Alternate code 2
"3": User code
0
R/W
○
Protocol code
SOHCODE
"0" to "255"
1
(0x01)
R/W
○
SOH
STXCODE
"0" to "255"
2
(0x02)
R/W
○
STX
CRCODE
"0" to "255"
13
(0x0D)
R/W
○
CR
CNTCODE
"0" to "255"
94
(0x5E)
R/W
○
CNT
LABEL_ROTATION
"0"
:
0 degree
"1" : 90 degree
"2" : 180 degree
"3"
:
270 degree
0
R/W
○
Label Rotation
SOP_EMULATION
"0"
:
Disable
"1" : Prodigy Plus - 110
"2" : Allegro - 220
"3" : Prodigy - 250
"4"
:
Auto
4
(Auto)
R/W
○
SOP Emulation
COMPATIBLE_TTF
"0"
:
Disable
"1" : Enable
0
R/W
○
Compatibility TTF
COMPATIBLE_GRAPHICS
"0"
:
Disable
"1" : Enable
0
R/W
○
Compatibility Graphics
RIGHT_TO_LEFT_PRINT
"0"
:
Disable
"1" : Enable
1
R/W
○
Right
-
to
-
left printing
RECEIVE_TIMEOUT
"0"
:
Disable
"1" to “9999” (milliseconds)
0
R/W
○
Receive time
-
out
FEED_ON_BLANK
"0"
:
Disable
"1" : Enable
1
R/W
○
Feed on blank item
FORMAT_ATTRIBUTE_PRIORITIZE
"0"
:
Commands
"1" : Settings
0
R/W
○
Format Attribute’s
priority
FORMAT_ATTRIBUTE
"0"
:
XOR
"1" : Transparent
"2" : Opaque
"3"
:
Inverse
0
R/W
○
Format Attribute
PAUSE_MODE_PRIORITIZE
"0"
:
Commands
"1" : Settings
0
R/W
○
Pause Mode’s priority
PAUSE_MODE
"0"
:
Disable
"1" : Enable
0
R/W
○
Pause Mode
1BYTE_CODEPAGE_PRIORITIZE
"0"
:
Commands
"1" : Settings
0
R/W
○
1 Byte Codepage’s
priority
1BYTE_CODEPAGE
"0"
:
UTF8
"1" : 8859-1
"2" : 8859-2
"3" : 8859-5
"4" : 852
"5" : 850
"6" : 858
"7"
:
1252
5
(850)
R/W
○
1 Byte
Codepage
UNIT_PRIORITIZE
"0"
:
Commands
"1" : Settings
0
R/W
○
SDPL Measure Unit’s
priority
UNIT
"0":inch
"1":mm
0
R/W
○
SDPL Measure Unit
FONT_STYLE_PRIORITIZE
"0"
:
Commands
"1" : Settings
0
R/W
○
Scalable Font Style’s
priority
BOLD_STYLE
"0"
:
Disable
"1" : Enable
0
R/W
○
Bold Style
ITALIC_STYLE
"0"
:
Disable
"1" : Enable
0
R/W
○
Italic Style
SENSOR_PRIORITIZE
"0"
:
Commands
"1" : Settings
0
R/W
○
Sensor’s priority
STATUS_REPLY_PRIORITIZE
"0"
:
Commands
"1" : Settings
0
R/W
○
Feedback
character
reply’s priority
STATUS_REPLY
"0"
:
Disable
"1" : Enable
1
R/W
○
Feedback character
reply
SOH_COMMAND_PRIORITIZE
"0"
:
Commands
"1" : Settings
0
R/W
○
SOH command’s priority
SOH_COMMAND(ALL)
"0"
:
Disable
"1" : Enable
"2"
:
Custom
1
R/W
○
All
SOH commands
SOH_COMMAND(SOH
-
B)
"0"
:
Disable
"1" : Enable
1
R/W
○
SOH
-
B commands
SOH_COMMAND(SOH
-
C)
"0"
:
Disable
"1" : Enable
1
R/W
○
SOH
-
C commands
SOH_COMMAND(OTHERS)
"0"
:
Disable
"1" : Enable
1
R/W
○
Other SOH commands

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
