[Return data]
Symbol Parameter name Valid range
a Total number of data byte
* This is the total number of bytes after
parameter b. The delimiting comma between
parameters a and b, and the ETX are not
included.
* Data input and output form is which case of
ASCII or HEX, but, as for the unit, the value
becomes same for a byte.
Data size from the first memory data item until
before [ETX]
Maximum 4 digits
b Memory data Refer to [Return status format] below.
[Return data format (when a command error occurs)]
[NAK]<15>
16
[Exception processing]
Exception conditionParameter name
A value outside the range is specified
Identifier Command error
Terminology Description
Command error The data received after a command error is determined is not considered as a
parameter of this command.
[Coding sample]
[DC2]PJ,H1,AS
* As for the identifier, two or more specification is possible excluding HA.
[DC2]PJ,H1,H2,AS
[DC2]PJ,H1,H2,H3,AS (Equal to [DC2]PJ,HA,AS)
[Return status format]
Current inlet type
＋”,”＋
RFID data
Description
Current inlet type 02: ICODE
03: Tag-it
05: my-d
06: RFID tag none/reading error
RFID data Refer to [Data format of RFID data] below.
[Data format of RFID data]
• When the command is issued specifying "H1" (user data) for the identifier
cc:d･･･d,e･･･
e
Symbol Parameter name Description
c Identifier UD: USER data (ASCII)
ud: USER data (HEX)
