SATO CL6NX Programming Reference

572
[Sample of status reply1] (format set to ASCII)
When '4912345678904' and DSFID code 55H, AFI code 10H, and EAS bit 1 are recorded in the
RFID tag of ICODE SLI of "E004010001D9CA2D", UID :.
Command [DC2]PJ,H1,AS
Status reply [STX]22,02,UD:13,4912345678904[ETX]
Command [DC2]PJ,H1,H3,AS
Status reply [STX]40,02,UD:13,4912345678904,DS:55,AF:10,EA:01[ETX]
USER data
Option flag data
USER data
Inlet type (ICODE)
Inlet type (ICODE)
[Sample of status reply 2] (format set to HEX)
When '4912345678904' is recorded in the RFID tag of Tag-it HF-I of "E00700002AC1E2BF", UID :.
(Data is not set to the optional flag data.)
Command [DC2]PJ,H1,HX
Status reply [STX]22,03,ud:13,34393132333435363738393034[ETX]
Command [DC2]PJ,H1,H2,HX
Status reply [STX]19,03,ud:13,34393132333435363738393034,UI:E00700002AC1E2BF[ETX]
USER data
UID data
USER data
Inlet type (Tag-it)
Inlet type (ICODE)
[Sample of status reply 3]
When '4912345678904' and DSFID code 55H, AFI code 10H, and EAS bit 1 are recorded in the
RFID tag of ICODE SLI of "E004010001D9CA2D", UID :.
Command [DC2]PJ,H2,NO
Status reply [STX]22,02,UI:E004010001D9CA2D[ETX]
Command [DC2]PJ,H3,NO
Status reply [STX]20,02,DS:55,AF:10,EA:01[ETX]
Command [DC2]PJ,H2,H3,NO
Status reply [STX]40,02,UI:E004010001D9CA2D, DS:55,AF:10,EA:01
UID data
Option flag data
UID data
Inlet type (ICODE)
Inlet type (ICODE)
Option flag data
Inlet type (ICODE)

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
