SATO CL6NX Programming Reference

579
Symbol Parameter name Description
e Data Refer to [Maximum return data] below.
[Maximum return data]
Command identifier Current inlet type Return number
of bytes
N1: USER data 01: ISO/IEC14443 TypeA 2048(ASCII)
4096(HEX)
N2: UID data 01: ISO/IEC14443 TypeA 14(HEX)
[Sample of status reply1] (format set to ASCII)
When '4912345678904' is recorded in the RFID tag of NTAG210 of "04 04 01 00 01 D9 CA", UID :.
Command [DC2]PJ,N1,AS
Status reply [STX]22,01,UD:13,4912345678904[ETX]
USER data
Inlet type (ISO/IEC14443 TypeA)
Command [DC2]PJ,N1,N2,AS
Status reply [STX]20,01,UD:13,4912345678904,UI:0404010001D9CA[ETX]
USER data UID data
USER data
Inlet type (ISO/IEC14443 TypeA)
Inlet type (ISO/IEC14443 TypeA)
[Sample of status reply 2] (format set to HEX)
When '4912345678904' is recorded in the RFID tag of MIFARE Ultralight of "04 07 00 00 2A C1 E2",
UID :.
Command [DC2]PJ,N1,HX
Status reply [STX]19,01,ud:13,34393132333435363738393034[ETX]
Command [DC2]PJ,N1,N2,HX
Status reply [STX]20,01, Inlet type (ISO/IEC14443 TypeA)
ud:13,34393132333435363738393034, USER data
UI:040700002AC1E2[ETX]
UID data
* It actually becomes continuous data.
USER data
Inlet type (ISO/IEC14443 TypeA)

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
