585
Symbol Parameter name Valid range
b Memory data Refer to [Return status format] below.
[Return data format (when a command error occurs)]
[NAK]<15>
16
[Exception processing]
Exception conditionParameter name
A value outside the range is specified
Identifier Command error
Terminology Description
Command error The data received after a command error is determined is not considered as a
parameter of this command.
[Coding sample]
[DC2]PJ,F1,AS
* As for the identifier, two or more specification is possible excluding FA.
[DC2]PJ,F1,F2,AS (Equal to [DC2]PJ,FA,AS)
[Return status format]
Current inlet type + "," + RFID data
Description
Current inlet type 04: FeliCa Lite/FeliCa Lite-S
06: RFID tag none/reading error
RFID data Refer to [Data format of RFID data] below.
[Data format of RFID data]
• When the command is issued specifying "F1" (user data) for the identifier
cc:d･･･d,e･･･
e
Symbol Parameter name Description
c Identifier UD: USER data (ASCII)
ud: USER data (HEX)
d Bytes of data Data input and output form is which case of ASCII or
HEX, but, as for the unit, the value becomes same for a
byte.
e Data Refer to [Maximum return data] below.
• When the command is issued specifying "F2" (ID data) for the identifier
cc:e…e,ff:h…h,ii:k…k
Symbol Parameter name Description
c / f / i Identifier DM: IDm
PM: PMm
ID: ID Block
