Section 06 ENGINE MANAGEMENT (RFI)

Subsection 01 (OVERVIEW)

Intake air

pressure

Crankshaft

Position

Sensor (CPS)

Crankshaft

position and

engine speed

Throttle valve

position (Idle to

wide open throttle)

Engine

temperature

Intake air

temperature

Battery

voltage

Start/stop

signal

Air Pressure

Sensor

(APS)

Water

Temperature

Sensor (WTS)

Air

Temperature

Sensor (ATS)

Fuel tank

Fuel filter

Fuel pump

Regulator

Injectors

Multi-Purpose Electronic Module

(MPEM)

Electronic Control Unit

(ECU)

PARAMETERS

SENSORS

FUEL

DELIVERY

Throttle

Position

Sensor (TPS)

To engine

F07F0NS

SIGNAL MANAGEMENT
