Section 07 ENGINE MANAGEMENT (DI)
Subsection 01 (OVERVIEW)
The MPEM distributes power from battery to all
accessories (except bilge pump which is connect-
ed to battery power). Accessories are protected
by fuses integrated in the MPEM, in fuse holder(s)
close to MPEM or in the electrical box. Fuses are
identified besides their holder.
IMPORTANT: The sensors and injectors are con-
tinuously powered with the supply from the bat-
tery. The MPEM switches the ground to com-
plete the electrical circuits it controls. Take this
into account when troubleshooting the electrical
system.
smr2004-Complete Line Up 331
