Section10FUELSYSTEM

Subsection 01 (FUEL CIRCUIT)

XP DI Models

22 Nm

(16 lbfft)

Loctite

243

F12F18S

Body

4 Nm

(35 lbfin)

Loctite 243

25 Nm

(18 lbfft)

Silicone

sealant

Primer N

Loctite 243

8 Nm

(71 lbfin)

7 Nm

(62 lbfin)

Anti-seize

lubricant

500 smr2004-Complete Line Up
