Section10FUELSYSTEM

Subsection 01 (FUEL CIRCUIT)

GTX 4-TEC Supercharged and GTX 4-TEC Limited Supercharged

22 Nm

(16 lbfft)

F18F0RS

4 Nm

(35 lbfin)

4 Nm

(35 lbfin)

Engine

smr2004-Complete Line Up 503

www.SeaDooManuals.net
