Section12ELECTRICALSYSTEM
Subsection 04 (INSTRUMENTS AND ACCESSORIES)
Removal
Remove muffler.
Turn depth gauge counterclockwise and pull it out.
1
F18H1EA
1. Depth gauge
Inspection
Ensure the silicone pad is in good condition. There
must be no air between the bottom of the depth
gauge and the hull. Otherwise, the gauge will not
work.
If silicone pad is damaged, replace it.
Installation
Ensure O-ring is in good condition and in place.
After installation, try pulling the gauge out to en-
sure it is properly locked.
Test run gauge.
608 smr2004-Complete Line Up
