Section 13 PROPULSION

Subsection 02 (DRIVE SYSTEM)

XP DI Models

F08J0ES

Loctite

243

22 Nm

(16 lbfft)

Loctite

243

22 Nm

(16 lbfft)

Loctite

271

Loctite

518

Synthetic

grease

Loctite

518

10 Nm

(89 lbfin)

Synthetic

grease

Synthetic

grease

Loctite

243

Synthetic

grease

Synthetic

grease

Loctite

243

22 Nm

(16 lbfft)

2 Nm

(18 lbfin)
