Section 14 STEERING SYSTEM
Subsection 01 (STEERING SYSTEM)
XP DI Models
F08K0ST
10 Nm
(89 lbfin)
Loctite 243
4 Nm
(35 lbfin)
6
9
1 Nm
(9 lbfin)
2
3
4
1
5
24
7 Nm
(62 lbfin)
18
8
13
Synthetic
grease
7 Nm
(62 lbfin)
7
Loctite
243
10
26 Nm
(19 lbfft)
13 Nm
(10 lbfft)
Engine
cover
Loctite
243
2.5 Nm
(22 lbfin)
Loctite
243
Loctite
243
20
19
6 Nm
(53 lbfin)
11
21
2.5 Nm
(22 lbfin)
23
7 Nm
(62 lbfin)
22
26
25
27
Engine
cover
17
6 Nm
(53 lbfin)
Loctite
243
16
15
7 Nm
(62 lbfin)
Synthetic
grease
14
7
10 Nm
(89 lbfin)
12
1 Nm
(9 lbfin)
3 Nm
(27 lbfin)
