Section 14 STEERING SYSTEM

Subsection 02 (ALIGNMENT)

F01H6WA

1. Remove storage basket

F08K03B

TYPICAL — XP DI MODELS

1. Support

2. Adjustment nut

3. Loosen bolts

All Models

After adjustment, torque retaining block bolts to

6N•m(53lbf•in).

CAUTION: Verify when the handlebar is turned

completely to the left or right side, that there is

no interference with venturi or VTS ring (if so

equipped).
