Siemens MICROMASTER 440 - BI: Fixed Freq. Selection Bit 1 - 4

Parameter Description Issue 01/06
MICROMASTER 440 Parameter List
118 6SE6400-5BB00-0BP0
P1021[3] BI: Fixed freq. selection Bit 1 Min: 0:0
CStat: CT Datatype: U32 Unit: - Def: 0:0
P-Group: COMMANDS Active: first confirm QuickComm.: No Max: 4000:0
Defines origin of fixed frequency selection.
Index:
P1021[0] : 1st. Command data set (CDS)
P1021[1] : 2nd. Command data set (CDS)
P1021[2] : 3rd. Command data set (CDS)
Dependency:
Accessible only if P0701 - P0706 = 99 (function of digital inputs = BICO)
Details:
See P1020 (fixed frequency selection Bit 0) for most common settings
P1022[3] BI: Fixed freq. selection Bit 2 Min: 0:0
CStat: CT Datatype: U32 Unit: - Def: 0:0
P-Group: COMMANDS Active: first confirm QuickComm.: No Max: 4000:0
Defines origin of fixed frequency selection.
Index:
P1022[0] : 1st. Command data set (CDS)
P1022[1] : 2nd. Command data set (CDS)
P1022[2] : 3rd. Command data set (CDS)
Dependency:
Accessible only if P0701 - P0706 = 99 (function of digital inputs = BICO)
Details:
See P1020 (fixed frequency selection Bit 0) for most common settings
P1023[3] BI: Fixed freq. selection Bit 3 Min: 0:0
CStat: CT Datatype: U32 Unit: - Def: 722:3
P-Group: COMMANDS Active: first confirm QuickComm.: No Max: 4000:0
Defines origin of fixed frequency selection.
Index:
P1023[0] : 1st. Command data set (CDS)
P1023[1] : 2nd. Command data set (CDS)
P1023[2] : 3rd. Command data set (CDS)
Dependency:
Accessible only if P0701 - P0706 = 99 (function of digital inputs = BICO)
Details:
See P1020 (fixed frequency selection Bit 0) for most common settings
r1024 CO: Act. fixed frequency Min: -
Datatype: Float Unit: Hz Def: -
P-Group: SETPOINT Max: -
Displays sum total of selected fixed frequencies.
P1025[3] Fixed frequency mode - Bit 4 Min: 1
CStat: CT Datatype: U16 Unit: - Def: 1
P-Group: SETPOINT Active: first confirm QuickComm.: No Max: 2
Direct selection or direct selection + ON for bit 4
Possible Settings:
1 Direct selection
2 Direct selection + ON command
Index:
P1025[0] : 1st. Command data set (CDS)
P1025[1] : 2nd. Command data set (CDS)
P1025[2] : 3rd. Command data set (CDS)
Details:
See parameter P1001 for description of how to use fixed frequencies.
P1026[3] BI: Fixed freq. selection Bit 4 Min: 0:0
CStat: CT Datatype: U32 Unit: - Def: 722:4
P-Group: COMMANDS Active: first confirm QuickComm.: No Max: 4000:0
Defines origin of fixed frequency selection.
Index:
P1026[0] : 1st. Command data set (CDS)
P1026[1] : 2nd. Command data set (CDS)
P1026[2] : 3rd. Command data set (CDS)
Dependency:
Accessible only if P0701 - P0706 = 99 (function of digital inputs = BICO).
Details:
See P1020 (fixed frequency selection Bit 0) for most common settings.
Level
3
Level
3
Level
3
Level
3
Level
3
Level
3
