Siemens MICROMASTER 440 Parameter Guide

Parameter Description Issue 01/06
MICROMASTER 440 Parameter List
176 6SE6400-5BB00-0BP0
P1503[3] CI: Torque setpoint Min: 0:0
CStat: T Datatype: U32 Unit: - Def: 0:0
P-Group: CONTROL Active: first confirm QuickComm.: No Max: 4000:0
Selects source of torque setpoint for torque control.
Index:
P1503[0] : 1st. Command data set (CDS)
P1503[1] : 2nd. Command data set (CDS)
P1503[2] : 3rd. Command data set (CDS)
Details:
See parameter P1501.
r1508 CO: Torque setpoint Min: -
Datatype: Float Unit: Nm Def: -
P-Group: CONTROL Max: -
Displays torque setpoint before limitation.
Details:
See parameter P1501.
3.29.2.5 Supplementary torque setpoint
P1511[3] CI: Additional torque setpoint Min: 0:0
CStat: T Datatype: U32 Unit: - Def: 0:0
P-Group: CONTROL Active: first confirm QuickComm.: No Max: 4000:0
Selects source of additional torque setpoint for torque and speed control.
Index:
P1511[0] : 1st. Command data set (CDS)
P1511[1] : 2nd. Command data set (CDS)
P1511[2] : 3rd. Command data set (CDS)
Details:
See parameter P1501.
r1515 CO: Additional torque setpoint Min: -
Datatype: Float Unit: Nm Def: -
P-Group: CONTROL Max: -
Displays additional torque setpoint.
Details:
See parameter P1501.
r1518 CO: Acceleration torque Min: -
Datatype: Float Unit: Nm Def: -
P-Group: CONTROL Max: -
Displays acceleration torque.
Details:
See parameter P1501.
P1520[3] CO: Upper torque limit Min: -99999.00
CStat: CUT Datatype: Float Unit: Nm Def: 5.13
P-Group: CONTROL Active: Immediately QuickComm.: No Max: 99999.00
Specifies fixed value for upper torque limitation.
P1520
max
P1520
def
r0333 1.5 ⋅=
r0333 4 ⋅±=
Index:
P1520[0] : 1st. Drive data set (DDS)
P1520[1] : 2nd. Drive data set (DDS)
P1520[2] : 3rd. Drive data set (DDS)
Level
3
Level
2
Level
3
Level
2
Level
3
Level
2
www . ElectricalPartManuals . com

Siemens MICROMASTER 440 Specifications

General

Power Range	0.12 kW to 250 kW
Output Voltage	0 V to Input Voltage
Output Frequency	0 Hz to 650 Hz
Control Modes	Vector control
Overload Capability	150% for 60 seconds
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	PROFIBUS, DeviceNet, CANopen, Modbus RTU
Enclosure Rating	IP20
Ambient Temperature	-10°C to +50°C
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
