Issue 01/06 Parameter Description
MICROMASTER 440 Parameter List
6SE6400-5BB00-0BP0
47
r0209 Maximum inverter current Min: -
Datatype: Float Unit: A Def: -
P-Group: INVERTER Max: -
Displays maximum output current of inverter.
Dependency:
Parameter r0209 depends on the derating which is affected by pulse frequency P1800, ambient
temperature and altitude. The data of deration is given in the OPERATING INSRTRUCTION.
P0210 Supply voltage Min: 0
CStat: CT Datatype: U16 Unit: V Def: 230
P-Group: INVERTER Active: Immediately QuickComm.: No Max: 1000
Parameter P0210 defines the supply voltage.
Its default value depends upon the type of inverter. If P0210 does not correspond to the supply voltage, then
it must be modified.
When P0210 has been modified, the following thresholds are changed:
Dependency:
Optimizes Vdc controller, which extends the ramp-down time if regenerative energy from motor would
otherwise cause DC link overvoltage trips.
Reducing the value enables controller to cut in earlier and reduce the risk of overvoltage.
Set P1254 ("Auto detect Vdc switch-on levels") = 0. Cut-in levels for Vdc-controller and compound braking
are then derived directly from P0210 (supply voltage).
0210P21.13 ⋅⋅=
0210P21.15 ⋅⋅=
0210P21.13 ⋅⋅=
0210P2 P1245 ⋅⋅=
Dynamic braking switch-on level
Compound braking switch-on level
Vdc_max switch -on level
Vdc_min switch -on level
Note:
- If mains voltage is higher than value entered, automatic deactivation of the Vdc controller may occur to
avoid acceleration of the motor. An alarm will be issued in this case (A0910).
- Default value is depending on inverter type and its rating data.
r0231[2] Max. cable length Min: -
Datatype: U16 Unit: m Def: -
P-Group: INVERTER Max: -
Indexed parameter to display maximum allowable cable length between inverter and motor.
Index:
r0231[0] : Max. allowed unscreened cable length
r0231[1] : Max. allowed screened cable length
Notice:
For full EMC compliance, the screened cable must not exceed 25 m in length when an EMC filter is fitted.
Level
2
Level
3
Level
3
