Issue 01/06 Parameter Description
MICROMASTER 440 Parameter List
6SE6400-5BB00-0BP0
75
3.8 Command source
P0700[3] Selection of command source Min: 0
CStat: CT Datatype: U16 Unit: - Def: 2
P-Group: COMMANDS Active: first confirm QuickComm.: Yes Max: 6
Selects digital command source.
Possible Settings:
0 Factory default setting
1 BOP (keypad)
2 Terminal
4 USS on BOP link
5 USS on COM link
6 CB on COM link
Index:
P0700[0] : 1st. Command data set (CDS)
P0700[1] : 2nd. Command data set (CDS)
P0700[2] : 3rd. Command data set (CDS)
Example:
Changing form P0700 = 1 to P0700 = 2 sets all digital inputs to default settings.
BOP
USS
BOP link
USS
COM link
P0700 = 2
Terminals
CB
COM link
Sequence control
Setpoint
channel
Motor
control
Caution:
Be aware, by changing of parameter P0700 all BI parameters are reset to the default value or modified as
listed in the table below.
If the Inverter is being controlled via the AOP, select USS (with the corresponding interface) for the
Command Source. If the AOP is connected to the BOP-Link Interface, then set Parameter P0700 to the
value 4 (P0700 = 4).
Note:
Changing this parameter sets (to default) all settings on item selected (see table).
P0700 = 0 P0700 = 1 P0700 = 2 P0700 = 4 P0700 = 5 P0700 = 6
P0701 1 0 1 0 0 0
P0702 12 0 12 0 0 0
P0703 9 9 9 9 9 9
P0704151515151515
P0705151515151515
P0706151515151515
P0707 0 0 0 0 0 0
P0708 0 0 0 0 0 0
P0731 52.3 52.3 52.3 52.3 52.3 52.3
P0732 52.7 52.7 52.7 52.7 52.7 52.7
P0733 0.0 0.0 0.0 0.0 0.0 0.0
P0800 0.0 0.0 0.0 0.0 0.0 0.0
P0801 0.0 0.0 0.0 0.0 0.0 0.0
Level
1
