Parameter Description Issue 01/06
MICROMASTER 440 Parameter List
110 6SE6400-5BB00-0BP0
3.16 Setpoint source
P1000[3] Selection of frequency setpoint Min: 0
CStat: CT Datatype: U16 Unit: - Def: 2
P-Group: SETPOINT Active: first confirm QuickComm.: Yes Max: 77
Selects frequency setpoint source. In the table of possible settings below, the main setpoint is selected from
the least significant digit (i.e., 0 to 7) and any additional setpoint from the most significant digit (i.e., x0
through to x7).
Possible Settings:
0 No main setpoint
1 MOP setpoint
2 Analog setpoint
3 Fixed frequency
4 USS on BOP link
5 USS on COM link
6 CB on COM link
7 Analog setpoint 2
10 No main setpoint + MOP setpoint
11 MOP setpoint + MOP setpoint
12 Analog setpoint + MOP setpoint
13 Fixed frequency + MOP setpoint
14 USS on BOP link + MOP setpoint
15 USS on COM link + MOP setpoint
16 CB on COM link + MOP setpoint
17 Analog setpoint 2 + MOP setpoint
20 No main setpoint + Analog setpoint
21 MOP setpoint + Analog setpoint
22 Analog setpoint + Analog setpoint
23 Fixed frequency + Analog setpoint
24 USS on BOP link + Analog setpoint
25 USS on COM link + Analog setpoint
26 CB on COM link + Analog setpoint
27 Analog setpoint 2 + Analog setpoint
30 No main setpoint + Fixed frequency
31 MOP setpoint + Fixed frequency
32 Analog setpoint + Fixed frequency
33 Fixed frequency + Fixed frequency
34 USS on BOP link + Fixed frequency
35 USS on COM link + Fixed frequency
36 CB on COM link + Fixed frequency
37 Analog setpoint 2 + Fixed frequency
40 No main setpoint + USS on BOP link
41 MOP setpoint + USS on BOP link
42 Analog setpoint + USS on BOP link
43 Fixed frequency + USS on BOP link
44 USS on BOP link + USS on BOP link
45 USS on COM link + USS on BOP link
46 CB on COM link + USS on BOP link
47 Analog setpoint 2 + USS on BOP link
50 No main setpoint + USS on COM link
51 MOP setpoint + USS on COM link
52 Analog setpoint + USS on COM link
53 Fixed frequency + USS on COM link
54 USS on BOP link + USS on COM link
55 USS on COM link + USS on COM link
57 Analog setpoint 2 + USS on COM link
60 No main setpoint + CB on COM link
61 MOP setpoint + CB on COM link
62 Analog setpoint + CB on COM link
63 Fixed frequency + CB on COM link
64 USS on BOP link + CB on COM link
66 CB on COM link + CB on COM link
67 Analog setpoint 2 + CB on COM link
70 No main setpoint + Analog setpoint 2
71 MOP setpoint + Analog setpoint 2
72 Analog setpoint + Analog setpoint 2
73 Fixed frequency + Analog setpoint 2
74 USS on BOP link + Analog setpoint 2
75 USS on COM link + Analog setpoint 2
76 CB on COM link + Analog setpoint 2
77 Analog setpoint 2 + Analog setpoint 2
Level
1
